This equipment is widely used for the sintering of inorganic materials (such as ceramic seals, silicon carbide, zirconia, zinc oxide, alumina, etc.) and metal materials (such as cemented carbide) under vacuum or protective atmospheres. It is suitable for processes like annealing, brazing, sintering, and degassing of metal materials under high vacuum and high-temperature conditions. The equipment is also ideal for dehydroxylation treatment of quartz materials.
Model | JYZF1-4RJ |
Specifications | 1400℃-Φ220×600mm |
Power Supply | AC 380V ±10%, 3-phase, 5-wire system, 50Hz/60Hz |
Total Heating Power | Approximately 32kW |
Maximum Temperature | 1400℃ |
Working Zone Dimensions | Φ220×600mm |
Temperature Control Zones | 1 zone |
Temperature Accuracy | ±1℃ |
Cold-State Ultimate Vacuum | 6.67×10⁻³Pa (empty furnace, cold state, after degassing) |
Protective Atmosphere | N2或Ar |
Charging Pressure | ≤0.03MPa |
Overall Dimensions | 1250×850×1800m（L×W×H） |
Total Equipment Weight | 400Kg |
Integrated Design: The equipment features a compact structure with a visually appealing design. It includes a built-in furnace wheel for easy and fast relocation.
Bottom-Lift Structure: The equipment adopts a bottom-lifting design, providing a delicate structure and ease of loading and unloading materials.
High Automation: The system uses a touch screen and PLC control for high automation, making operations intuitive and efficient. The operation screen displays the status and data of various components in real time.
Process Control and Data Management: The system supports online process editing, storage, calling, uploading, and downloading functions. Dozens of sintering processes can be pre-stored in the touch screen for easy reuse, eliminating the need for repeated editing and minimizing errors that could damage products.
Real-Time Data Recording: The sintering temperature, vacuum level, and other data can be recorded in real time. Users can start and stop data recording as needed, helping to eliminate unnecessary data and making it easy to query and export data.
High Sintering Temperature: The equipment utilizes a molybdenum filament heating element, which supports high sintering temperatures.
